• Dimensions: Weight890 lbs. (404 kg.)
  • Chassis: TiresRear: 4.80 x 8 pneumatic Front: 4.80 x 8 Load Range B, Pneumatic
  • Performance: Range20 miles (32 km)
  • Performance: Load Capacity600 lbs. (272 kg)
  • Interior: SeatsDriver: Seat Cushion with Full Backrest Passenger: N/A
  • Performance: Tow Capacity2,000 lbs. (909 kg)
  • Chassis: Frame ConstructionAll steel unitized body, heavy duty 14 gauge smooth plate
  • Chassis: PowertrainType: Electric Power: 110/220V, 50/60Hz Transmission: Transaxle Assembly, Sealed Helical Gear Reduction Drive: Direct Drive Controller: Solid State Speed Control
  • Chassis: BatteryType: Four 210 amp hr., 6 volt (lead acid) System Voltage: 24 Charger: Portable, 25 Amp, SCR Control
  • Chassis: BrakesRear: Two wheel mechanical drum with brake light Front: N/A Parking: Foot Operated
  • Performance: Passengers1
  • Chassis: SuspensionRear: Front:
  • Interior: InstrumentationBattery status indicator, forward/reverse selector, key switch, reverse buzzer and electric horn
  • Performance: Speed9 mph (14.4 km/h)
  • Dimensions: Hitch HeightN/A
  • Chassis: SteeringManual, Tiller, Front Fork
  • Dimensions: Width32" (81 cm)
  • Dimensions: Length86" (218 cm)
  • Dimensions: Wheel Base55.5" (140.0cm)
  • Dimensions: Outside Turning Radius81" (205.1cm)
  • Dimensions: HeightLess Cab: 40" (102 cm) With Cab: N/A
  • Dimensions: DeckWidth: 30" (76.2cm) Length: 27" (68.6cm) Height: 36" (91.4cm)
