  • Overall Specifications
    Overall Width
    5’ 11” (1.81 m)
    Turning Radius (Outside)
    125” (3.17 m)
    Maximum Lift Capacity
    5,500 lbs (2,495 kg)
    Maximum Lift Height
    19’ 1” (5.82m)
    Rated Lift Capacity @ Maximum Height
    4,400 lbs (1,996 kg)
    Maximum Forward Reach
    11’ 3” (3.44m)
    Rated Lift Capacity @ Maximum Reach
    1,900 lbs (862 kg)
    O/A Length - LessForks
    13’ 1” (3.97 m)
    Overall Height - Stowed
    6’ 3” (1.90 m)
    Operating Weight
    10,500 lbs (4,763 kg)
    Engine
    74hp Deutz TCD 2.2L T4F
    Max Travel Speed - Forward
    17mph (27 km/h)
    Transmission
    Hydrostatic, 1 F/R
    Axles
    Dana
    Steering
    3 Mode (Front Wheel, 4 Wheel, Crab)
    Tires
    Pneumatic 12 x 16.5 12PR Grip Lug
