SX-125 XC

  • Genie
  • Telescopic Boom Lift

Find Your Nearest Location

Your Preferred Store
Change location Change location
Request Quote
Key Features & Specs

Perfect for heavy lifting in construction, bridge inspections and maintenance, stadium and sports arena, oil and gas, industrial, telecommunications and utility applications, the Genie® SX-125 XC™ telescopic boom works in more applications that require higher capacities thanks to its industry-leading dual lift capacity — 660-lb (300 kg)/1,000-lb (454 kg)**.

Overview

  • Smooth range of motion envelope — no more saw tooth
  • Mini Genie XChassis™ design for compact transportation and work in confined areas
  • Load sense technology for accurate load weighing and zero-load field calibration
  • Extended reach out and down capability with 8 ft 1 in (2.69 m) of reach below grade



** Maximum outreach zone / maximum capacity zone.

  • + Expand All
  • - Close All
  • Options

    Engine Options

    • Diesel intake air pre-cleaner
    • Cold weather kit: 5W-40 synthetic engine oil, oil pan heater, battery heater, and hydraulic tank heater

    Lift/Turntable Options

    • Hostile environment kit: Cylinder bellows, boom wiper seals, air pre-cleaner, and ring gear guard

    Platforms

    • 6 ft. dual entry or 8 ft. tri entry platform with ½ height mesh inserts and side swing gate
    • 6 ft. dual entry platform with side swing gate

    Platform Options

    • Panel cradle package
    • Platform auxiliary top rail
    • Thumb rocker steering
    • Welder - Select Lincoln or Miller
    • Traveling fall arrest anchor system: requires 6ft platform
    • Traveling fall arrest anchor system: requires 8ft platform
  • Below Ground Reach: 8 ft 10 in | 2.69 m
  • Max Horizontal Reach: 80 ft | 24.38 m
  • Max Platform Height: 125 ft | 38.1 m
  • Machine Width and Length: 12 ft 11 in / 46 ft 9 | 3.94 m / 14.24 m
  • Platform Capacity: 660 lb Unrestricted, 1000 lb Restricted | 300 kg Unrestricted, 454 kg Restricted
